Understanding Domain Entities [with Examples] - DDD w/ TypeScript

May 28th, 2019 / 12 min read / Share / Edit on GitHub
Entities are the first natural place we should aim to place business logic in domain-driven applications. In this article, we talk about the roles and lifecycle of an entity in Domain-Driven Design.

This is part of the Domain-Driven Design w/ TypeScript & Node.js course. Check it out if you liked this post.

Also from the Domain-Driven Design with TypeScript article series.

The biggest reason why companies move towards domain-driven design is because their business has taken on a necessary complexity.

Think about the amount of busiess logic complexity in some of the most common tools we use today like GitLab or Netlify. They're truly not dealing with modeling basic CRUD apps.

In order to manage business logic complexity, the approach is to use object oriented programming concepts to model complex behaviour between objects; replicating what should happen in a particular domain when it's possible and when it's not possible.

Domain-Driven introduces a set of artifacts that we can use to model the domain.

Let's talk about another one of the main artifacts: entities.


The role of entities in DDD

Entities are pretty much the bread and butter of domain modeling.

These are some of the primary trait of entities.

First place to put business logic (if it makes sense)

Entities should be the first place that we think of to put domain logic.

When we want to express what a particular model:

  • can do
  • when it can do it
  • what conditions dictate when it can do that thing

We aim to place that logic closest to the model that it belongs to.

For example: in a job board application where employers can leave questions for applicants to answer when they apply to jobs, we can enforce some rules.

Rule #1: You can't add a question to a job that already has existing applicants.

Rule #2: You can't add more than the max amount of questions for a job.

Here's a quick example:

class Job extends Entity<IJobProps> {
  // ... constructor
  // ... private factory method

  get questions (): QuestionsCollection {
    return this.props.questions;
  }

  public hasApplicants (): boolean {
    return this.props.applicants.length !== 0;
  }

  public addQuestion (question: Question) {
    if (this.hasApplicants()) {
      throw new Error("Can't add a question when there are already applicants to this job.")
    }

    if (this.props.questions.length === MAX_QUESTIONS_PER_JOB) {
      throw new Error("This job already has the max amount of questions.")
    }

    this.props.questions.push(question);
  }
}

Sometimes, it doesn't feel natural and doesn't make sense to put certain domain logic inside of an entity.

This happens when the logic we're trying figure out where to put doesn't involve one entity in particular. There are cases where it's OK (like our Job example utilizing the Question entity), but there are other cases where the two entities involved shouldn't necessarily know about each other (look into Aggregate Design) 1.

For example, if we were modeling a Movie Rental application, with a Customer entity and a Movie entity, where do we put the purchaseMovie() method?

A Customer can purchase a movie, but the Customer entity shouldn't need to know anything about Movies.

Conversely, a Movie can be purchased by a Customer. But we wouldn't want to reference a Customer in the Movie model, because ultimately, a Customer has nothing to do with a Movie.

This is the type of logic that we put in a Domain Service instead 2.

Enforcing model invariants

In one of my previous articles, I said that Domain-Driven Design is declarative.

Building an application with DDD is like creating a domain-specific language for your problem domain.

In order to do that, we need to ensure that we only expose operations that are meaningful and valid to the domain. We also ensure that class invariants are satisfied.

Validation logic on object creation is normally delegated to Value Objects, but what can happen (and when) is up to the entity.


One of the earliest mistakes I was making in domain modeling was exposing getters and setters for everything.

So let's be explicit about the fact that that's not the best thing to do.

Don't add getters and setters for everything.

There, I did my part.

The reason why it's not good is because we need to control how our objects change. We never want our objects to end up in an invalid state.

Take the job board example again (particularly the part about the QuestionsCollection).

class Job extends Entity<IJobProps> {
  // ... constructor
  // ... private factory method

  get questions (): QuestionsCollection {
    return this.props.questions;
  }

  public addQuestion (question: Question) {
    // ...
    if (this.props.questions.length === MAX_QUESTIONS_PER_JOB) {
      throw new Error("This job already has the max amount of questions.")
    }

    this.props.questions.push(question);
  }
}

Do you notice how the questions array doesn't have a setter defined for it?

Our domain logic specifies that someone shouldn't be able to add more than the max amount of questions per job.

If we had a public setter for questions, there's nothing stopping someone from completely circumventing the domain logic by doing:

job.questions = [{}, {}, {}, {}, {}, ...] // question objects

This is encapsulation: one of the 4 principles of Object-oriented programming. Encapsulation is an act of data integrity; and that's especially important in domain-modeling.

Identity and lookup

An entity is different from a Value Object primarily due to the fact that an Entity has an identity while a Value Object does not.

Entities: think User, Job, Organization, Message, Conversation.

Value Objects: think Name, MessageText, JobTitle, ConversationName.

Typically, a single Entity will be a model that references other Value Objects and Entities.

Here's what a basic User entity might look like.

interface IUserProps {
  name: Username;
  email: Email;
  active: boolean;
}

class User extends Entity<IUserProps> {
  get name (): Username {
    return this.props.name;
  }

  get email (): Email {
    return this.props.email;
  }

  private constructor (props: IUserProps, id?: UniqueEntityId) {
    super(props, id);
  }

  public isActive (): boolean {
    return this.props.active;
  }

  public static createUser (props: IUserProps, id?: UniqueEntityId) : Result<User> {
    const userPropsResult: Result = Guard.againstNullOrUndefined([
      { propName: 'name', value: props.name },
      { propName: 'email', value: props.email },
      { propName: 'active', value: props.active }
    ]);

    if (userPropsResult.isSuccess) {
      return Result.ok<User>(new User(props, id))
    } else {
      return Result.fail<User>(userPropsResult.error);
    }
  }
}

During the lifecycle of an entity, it may need to be Stored to a database, Reconstituted and Modified before being deleted or archived.

I use UUIDs instead of Auto-incremented IDs for entity creation. See this article for why.

Entity lifecycle

This is what the lifecycle of an entity looks like, generally.

Creation

To create entities, just like Value Objects, we use Factories of some sort.

Most of the examples on this site use basic Factory methods.

What's a factory method?

Remember this bit in the previous example?

class User {
  // ...

  private constructor (props: IUserProps, id?: UniqueEntityId) {
    super(props, id);
  }

  public static createUser (props: IUserProps, id?: UniqueEntityId) : Result<User> {
    const userPropsResult: Result = Guard.againstNullOrUndefined([
      { propName: 'name', value: props.name },
      { propName: 'email', value: props.email },
      { propName: 'active', value: props.active }
    ]);

    if (userPropsResult.isSuccess) {
      return Result.ok<User>(new User(props, id))
    } else {
      return Result.fail<User>(userPropsResult.error);
    }
  }
}

The createUser method is a Factory Method that handles creation of the User entity.

Notice that we can't use the new keyword and do:

const user: User = new User(); // <= constructor is private

Again, encapsulation and data integrity. We want to control how instances of Users get into the execution of our domain layer code.

If we had hundreds of different types of Users that we wanted to be able to create, we could either write more factory methods, or we could try using Abstract Factories.

Entity base class

Note that you should never fully copy someone else's Entity or Value Object class. For something this important to your domain (this is essentially the family jewels), it would be worthwhile for you roll your own. You might have different needs, but feel free to start here and change as necessary.

import { UniqueEntityID } from './types';

const isEntity = (v: any): v is Entity<any> => {
  return v instanceof Entity;
};

export abstract class Entity<T> {
  protected readonly _id: UniqueEntityID;
  protected props: T;

  // Take note of this particular nuance here:
  // Why is "id" optional?
  constructor (props: T, id?: UniqueEntityID) {
    this._id = id ? id : new UniqueEntityID();
    this.props = props;
  }

  // Entities are compared based on their referential
  // equality.
  public equals (object?: Entity<T>) : boolean {

    if (object == null || object == undefined) {
      return false;
    }

    if (this === object) {
      return true;
    }

    if (!isEntity(object)) {
      return false;
    }

    return this._id.equals(object._id);
  }
}

Here's what's important to note about the Entity<T> base class:

  1. Entity<T> is an abstract class. This means that we can't instantiate it directly. We can, however, subclass it. That's a logical design decision. An entity only makes sense to exist if it has a particular type to it like Car extends Entity<ICarProps>.
  2. The id for this class is readonly. So it shouldn't be able to be changed once instantiated. Also a pretty logical design decision if you ask me.
  3. We're using the equals(object?: Entity<T>) method to determine if an entity is referentially equivalent to another entity. If referential equality doesn't determine that they're the same, we compare the id of this entity vs. the one we'recomparing it to.
  4. The props for the class are stored in this.props. The reason for that is because we want to leave the decision to the subclass on which properties getters and setters should be defined.

Optional id field

The most interesting design decision to note here is that the id field is optional.

Why would we do that?

Well, when the id is known (because we've already created it), we can pass it in.

When we don't know the id (because we haven't created it yet), we create a new one (32-bit UUID).

This allows us to address both the Creation and Reconstitution events in the entity lifecycle.

Storage

After we've created an entity in memory, we'll want a way to store it to the database.

This is done with the help of a Repository and a Mapper.

The Repository is an artifact used to persist and retrieve domain objects from whatever type of persistence technology you'd like (relational database, noSQL database, JSON file, text files).

The Mapper is a file that simply maps a domain object to the format needed to save it in a database, and vice versa (into a Domain object).

Here's the skeleton of a User repo utilizing the Sequelize ORM.

interface IUserRepo {
  exists (userId: string): Promise<boolean>;
  searchUsersByEmail(email: string): Promise<UsersCollection>;
  getUsers (config: IUserSearchConfig): Promise<UsersCollection>;
  getUsersByRole (config: IUserSearchConfig, role: Role): Promise<UsersCollection>;
  getUser(userId: string): Promise<any>;
  save(user: User): Promise<User>;
}

export class SequelizeUserRepo implements IUserRepo {
  private sequelizeModels: any;

  constructor (sequelizeModels: any) {
    this.sequelizeModels = sequelizeModels;
  }

  exists (userId: string): Promise<boolean> {
    // implement specific algorithm using sequelize orm
  }

  searchUsersByEmail(email: string): Promise<UsersCollection> {
    // implement specific algorithm using sequelize orm
  }

  getUsers (config: IUserSearchConfig): Promise<UsersCollection> {
    // implement specific algorithm using sequelize orm
  }

  getUsersByRole (
    config: IUserSearchConfig,
    role: Role
  ): Promise<UsersCollection> {
    // implement specific algorithm using sequelize orm
  }

  getUser(userId: string): Promise<any> {
    // implement specific algorithm using sequelize orm
  }

  save(user: User): Promise<User> {
    // implement specific algorithm using sequelize orm
  }
}

Let's say that we wanted to implement the getUsers method.

We'd want to retrieve all the users using the Sequelize-specific syntax, and then map those Active Records into User domain objects.

import { UserMap } from '../mappers'
export class SequelizeUserRepo implements IUserRepo {
  private sequelizeModels: any;

  // ...
  getUsers (config: IUserSearchConfig): Promise<UsersCollection> {
    const UserModel = this.sequelizeModels.BaseUser;
    const queryObject = this.createQueryObject(config);
    const users: any[] = await UserModel.findAll(queryObject);
    return users.map((u) => UserMap.toDomain(u))
  }
}

Here's what the mapper might look like:

export class UserMap extends Mapper<User> {
  public static toDTO (user: User): UserDTO {
    id: user.id.toString(),
    userName: user.name.value,
    userEmail: user.email.value
  }

  public static toPersistence (user: User): any {
    return {
      user_id: user.id.toString(),
      user_name: user.name.value,
      user_email: user.email.value,
      is_active: user.isActive()
    }
  }

  public static toDomain (raw: any): User {
    const nameOrResult = UserName.create
    const emailOrResult = UserEmail.create(raw.user_email);

    return User.create({
      name: UserName.create(raw.user_name).getValue(),
      email: UserPassword.create(raw.user_password).getValue(),
      active: raw.is_active,
    }, new UniqueEntityID(raw.user_id)).getValue()
  }
}

See how narrowly scoped this class is? It's a great example of the Single Responsibility Principle.

Reconstitution

After we've created an entity and persisted it into the database, at some point, we'll want to pull it out and use it for operations.

Again, this is a job easily maintained by the repository and mapper classes.

Conclusion

There's more to domain objects like Aggregate Roots and Domain Events but you can get started modeling a lot of your domain with just Entities and Value Objects.

In the next few articles, we'll talk about how to use Domain Events in a real world Sequelize + Node + TypeScript app and how to model Aggregates.

This is part of the Domain-Driven Design w/ TypeScript & Node.js course. Check it out if you liked this post.


  1. This branches into Aggregate Design. Certain entities do belong in scope of others. We call the entities at the top of this tree, an Aggregate Root.

  2. This is where we locate domain logic that doesn't belong to any one object conceptually. Not to be confused with an Application Service. Domain Services only operate on Domain Objects, whereas Application Services are artifacts that are unpure to the domain, that may pull data from external resources (APIs, object databases, etc, and so on).

Discussion

Thoughts? Share the article if you think it'll be useful to someone + join the discussion about this post on Twitter!


Stay in touch!



About the author

Khalil Stemmler

Khalil Stemmler is a Developer / Designer and co-founder of Univjobs. He frequently publishes articles about Advanced TypeScript & Node.js best practices for large-scale applications.




You may also enjoy...

A few more related articles

REST-first design is Imperative, DDD is Declarative [Comparison] - DDD w/ TypeScript
May 15th, 2019 / 11 min read
A comparison between designing Node.js applications using REST-first design and Domain-Driven Design.
An Introduction to Domain-Driven Design - DDD w/ TypeScript
Apr 9th, 2019 / 10 min read
Domain-Driven Design is the approach to software development which enables us to translate complex problem domains into rich, expr...
Value Objects - DDD w/ TypeScript
Apr 7th, 2019 / 6 min read
Value Objects are one of the primary components of Domain-Driven Design. Here's a simple Value Object class in TypeScript.
Migrate Primary Keys to UUIDs - Sequelize/Node
Apr 20th, 2019 / 9 min read
This is how and why I took upon myself the hellish task of migrating an existing Sequelize + TypeScript application to use UUIDs i...

Want to be notified when new content comes out?

Join 2000+ other developers learning about Domain-Driven Design and Enterprise Node.js.

I won't spam ya. 🖖 Unsubscribe anytime.

Get updates
